General

Differential pressure

See «SPECIFICATIONS» [1 bar =100 kPa]

Maximum viscosity

65 cSt (mm2/s)

Response time

5 - 25 ms

fluids ()

temperature range (TS)

seal materials ()

air, inert gas, water, oil

-25°C to +80°C

NBR (nitrile)

0°C to +60°C

UR (cast urethane)

Materials in contact with fluid

(¬) Ensure that the compatibility of the fluids in contact with the materials is verified

Body

Brass or Stainless steel, AISI 304

Shading coil

Copper or Silver

Core tube

Stainless steel, AISI 305

Core and plugnut

Stainless steel, AISI 430F

Springs

Stainless steel, AISI 302

Seal

NBR

Disc

NBR or UR

Disc holder (NO function)

PA

Electrical characteristics

Coil insulation class

F (AC) or H (DC)

Connector

Spade plug (cable Ø 6-10 mm)

Connector specification

ISO 4400 / EN 175301-803, form A

Electrical safety

IEC 335

Electrical enclosure protection

Moulded IP65 (EN 60529)

Standard voltages

DC (=) : 24V - 48V

(Other voltages and 60 Hz on request)

AC (~) : 24V - 48V - 115V - 230V/50 Hz

1/8

G262K001S1N00

8262K012S1N00

1/8

G262K002S1N00

8262K006S1N00

1/4

E262K019S1N00

8262K080S1N00

1/4

E262K022S1N00

8262K007S1N00

1/4

E262K110S1N00

E262K185S1N00
